13mm (1/2″) 84 N·m (750 in·lbs) Cordless Hammer Driver Drill 18V LXT® Li-Ion [Bare Tool]

DHP485Z

13mm • 1.6 – 1.9 kg (3.5 – 4.2 lbs) • 18V LXT® Li-Ion

Delivers up to 55% higher hammer drilling speed than previous model
Aluminum gear housing creates the impression of rigidity of the machine
Compact and ergonomic design at only 182 mm (7-1/8″) long
Variable 2-speed (0-500 & 0-1,900 RPM) for a wide range of drilling, fastening and hammer drilling applications
0-28,500 IPM for fast hammer drilling in masonry materials

Belt Clip

Features

Li-Ion

6.0

5.0

4.0

3.0

2.0

1.5

Net weight	1.6 – 1.9 kg (3.5 – 4.2 lbs)
Capacity	Steel / Wood / Masonry: 13 / 38 / 13 mm (1/2″ / 1-1/2″ / 1/2″)
Chuck capacity	1.5 – 13 mm (1/16 – 1/2″)
Impacts Per Minute (IPM)	High / Low: 0 – 30,000 / 0 – 7,500
No Load Speed (RPM)	High / Low: 0 – 2,000 / 0 – 500
Max Fastening Torque	Hard / Soft: 54 / 30 N·m (480 / 270 in.lbs.)
Max lock torque	60 N·m (530 in.lbs.)
Vibration Level	Hammer Drilling Into Concrete: 8.0 m/s²
	Drilling Into Metal: 2.5 m/s² or less
Sound Pressure Level	88 dB(A)
Sound Power Level	99 dB(A)
Dimensions (L x W x H)	182x79x261 mm (7-1/8″x3-1/8″x10-1/4″)
